RPLT-6000 high mast vehicle mounted mobile Lighting Tower

FOB Reference Price:Get Latest Price
$5,900.00 - $6,300.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
RPLT-6000 RPLT-6000 RPLT-6000 RPLT-6000
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Fujian, China (Mainland)
Brand Name:
Robust Power
Item type:
light tower
Engine:
Kubota D1105-BG Diesel
Engine Type:
3 Cylinders, In Line, Water Cooled
Prime Power:
6.7kw/50HZ 8.4KW/60HZ
Alternator:
Stamford
Lighting:
4*1000W metal halide
Lumen:
4*110000lm
Mast:
3-section 9m
Fuel Tank:
100L
Fuel con.:
2.0l/h
Supply Ability
Supply Ability:
200 Set/Sets per Month
Packaging & Delivery
Packaging Details
Plywood Tray/Plywood Cases/Cartons
Container Load(20GP/40HQ): 6/12 Sets
Extended Dimension(L*W*H): 4500*1350*1700MM
Port
Fuzhou
Lead Time :
Shipped in 30 days after payment

Features

Suitable for-events, emergency lighting, car parks ,general industry, auxiliary power supply.

The RPLT -6000 features a compact yet practical design, equipped with reliable Kubota engine powering ,4*1000W metal halide lamps.

Technical Specifications

GENARATOR

Engine

Kubota D1105-BG Diesel

Engine type

3 cylinders,in line, water cooled

Prime power

7.2kw/50hz  8.0kw/60hz

Engine speed

1500rpm    1800rpm

Engine aspiration

Natural

Alternator

Stamford PI044F/4-Pole,Brushless,excitation

Voltage

120,220,230,240v

Insulation

H

Fuel tank capacity

100L

Fuel consumption

2.0l/h(@100% full loading)

Maximum working hours

50

Control system

GU3303 Digital controller

Engine shutdown protection

Low oil press, over speed, over current,
high temperature detection, low fuel level

Auxiliary sockets

2

LIGHTING

Total power of lamps

4*1000w

Type of lamp

Metal halide lamp

Housing materials

Galvanization reflector housing

Lumen

4*110000

Lifetime of lamp

2000 hours

Working temperature

≤85

Connection protection index

IP54

MAST

Mast type

3-sections telescopic mast 9m

Total height

Top 9m

Rotation

358 degrees non-continuous

TRAILER

Operate for elevation

Winch mechanical

Tow hitch

Ring/ball hitch

Stabilize supports

4*manual

Tire size

13inch

Brakes

Manual

DIMENSION& weight

Dry /net weight

830/780kg

Retracted dimension(L*W*H)

4300*1350*1700mm

Shipping package

Iron pallet 1800*1250*1450mm
Plywood case 3500*300*260mm
Carton 510*510*430mm

Container load 20GP/40HQ

6/12set

Color

White/yellow/optional


Related Products




Robust Power Models:

No.ModelMastPower of LampsEngine Model
1RPLT16004.8M Manual4*400W Metal Halide LampRP186FA
2RPLT16004.8M Manual4*160W LEDRP186FA
3RPLT16004.8M Manual2*1000W Metal Halide LampRP186FA
4RPLT60009M Manual 4*1000W Metal Halide LampKubota D1105 (Japan)
5RPLT60009M Manual 4*240W LED Kubota D905 (Japan)
6RPLT68008.6M Hydraulic4*1000W Metal Halide LampKubota D1105 (Japan)
7RPLT68008.6M Hydraulic4*1500W Metal Halide LampKubota D1105 (Japan)
8RPLT68008.6M Hydraulic4*480W LED Kubota D905 (Japan)
9RPLT38007M Hydraulic4*480W LED Kubota Z482 (Japan)
10RPLT69008.5M Hydraulic4*480W LED Kubota D1105 (Japan)
11RPLT720010M Hydraulic6*480W LED Kubota D1105 (Japan)
12RPLT720010M Hydraulic4*720W LED Kubota D1105 (Japan)
13RPLT76009M Hydraulic6*480W LED Kubota D1105 (Japan)
14RPLT76009M Hydraulic4*720W LED Kubota D1105 (Japan)





More Mobile Light Tower Please Click On Our Factory Website
